G353A046 1 1/2” DN40 Right Angle Remote Pilot Diaphragm Dust Collector Bag Filter Pulse Jet Valve
Product Description
1. Specially designed for reverse jet-type dust collector systems.
2. Size: 3/4inch
3. High cycle life.
4. High flow Cv’s to 140 for effective bag cleaning.
Model code | G353A046 |
Material | stainless steel,Aluminum |
Port size | 1.5 inch |
Weight | 1.6kgs |
Voltage | N/A |
Used | Dust collector industry machinery |
Port Size | Remote Pilot Connection | Office Size | Operating Pressure Differential (Bar) | Model Number | Diaphragm Material | |
G | φB | (mm) | Min. | Max. | Aluminium | NBR/Viton |
3/4” | 1/8” | 24 | 0.35 | 8.5 | G353A041 | |
1” | 1/8” | 27 | 0.35 | 8.5 | G353A042 | |
1 1/2” | 1/8” | 52 | 0.35 | 8.5 | G353A045 | |
